| Brand Name : | GCL |
| Certification : | CE,RoHS,ISO9001,CCC |
| Model Number : | Model Number: GC-OFC-P3.91 |
| Price : | US $ 1,450 - 1,500 / Square Meter |
| Delivery Time : | 10-15days |
| Payment Terms : | L/C,D/A,D/P,T/T,Western Union,MoneyGram,paypal |
| Supply Ability : | 10000 Square Meter/Square Meters per Month |
indoor P3.91 diecasting led display rental screen full color P3.91 P4.81
Serial number | specification | P3.91 |
1 | Pitch | 3.91mm |
2 | Module Resolution | 64*64 |
3 | Module Size | 250mm×250mm |
4 | Weight of cabinet | 10KG |
5 | Cabinet size | 500mm×500mm/500mm*1000mm |
6 | Resolution/cabinet | 64×128=8192dot |
7 | Density | 65536dot/m2 |
8 | Driving method | Constant driving 1/16 Scan |
9 | Standard | SMD 3 in 1 |
10 | Viewing angle(H/V) | H:140° V:140° |
11 | Brightness | >1000nits |
12 | The optimal viewing distance | 5--100m |
13 | Display colors | 687million |
14 | Pixel configuration | 1R1G1B |
15 | Protection degree | IP31 |
16 | Power Consumption | Max:<700 Ave.<300 |
17 | Control mode | Video Sync |
18 | Display mode | Max: 1024×768 |
19 | LED parameters | R: λd:620-625nm IV:150-200mcd |
19 | LED parameters | G: λd:520-525nm IV:260-330mcd |
19 | LED parameters | B: λd:465-470nm IV:55-60mcd |
20 | Rate | ≥1200HZ |
21 | Communication | Cats≤120m Fiber optical:1000m |
22 | Encapsulation mode | Greeble |
Advantage:
1. Lightweight. Convenient in transporting and installing & saving
labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person
without tool.
4. Humanized operating interface with breakdown indicator lights,
easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving
the debugging technology for nice image.
